Baby Incubator For Hospital Use MSLBI01 Specifications
Temperature displayed by LED
Alarm functions: Power failure; Over temperature; Temperature deviation; Temperature sensor failure; Fan failure
>37℃ temperature setting
A keypad lock prevent inadvertent changes the setting
A second thermal cut-out function for more safety
Humidity by natural airway
Heating power displayed on panel
The infant bed inclination angle is adjustable
Main functions:
1.Microprocessor based servo controlled temperature system.
2.Temperatu re displayed by LED
3.Alarm functions : Power failure; over temperature; temperature deviation; temperature sensor failure;fan failure;
4.>37°C temperature setting
5. A keypad lock helps prevent inadvertent changes the setting
6. Temperature deviation and over temperature could be amended in front panel directly
7.The infant bed inclination angle is adjustable
8.Humidity is adjustable continuously
9.Integral timer to record therapy time
10.A second thermal cut-off function for more safety.
| Power supply | AC110/220V 60/50Hz | |
| Power input | 420VA | |
| Operating conditions | Environment temperature | 20℃ – 30℃ |
| Environment relative humidity | 30% – 75%RH | |
| Environment air velocity of flow | <0. 3m/s | |
| Air Temperature control range | 25℃ – 38℃ | |
| Temperature fluctuation | ±0.5℃ | |
| Uniformity of mattress temperature | ≤0. 8℃ | |
| Warm-up time | ≤45min | |
| Internal noise level | ≤55dB (A) | |
| Infant bed tilt angle | ±10° | |
| Mattress size | 65cm(L)+37cm(W) | |
| Trough capacity | 1200ml | |
| Air filter | 0.5um | |
High Quality Infant Baby Incubator for Hospital Use
MSLBI01
It is the advanced technology in such disciplines as comprehensive clinical medicine, machinery, computer automatic control, sensor, etc. that the baby in incubator, offers newborn baby and disease baby to a fine environment where air purify, temperature and humidity is suitable, similar to uterus of the parent.
The temperature of cabin space of the baby in incubator should be set up on the doctor’s order, Baby’s skin temperature, baby’s air temperature of the cabin and baby’s humidity of the cabin have digital display, when baby’s skin temperature and air temperature of the cabin over the normal value or present other unusual situations, there is alarming (power cut off, fan failure, sensor trouble, air temperature over, skin temperature over, deviation between display temperature and setting up temperature, etc.), guarantee the dependability and security of the one machine.
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
Guangdong
|
|
|
Brand Name
|
MSL
|
|
Model Number
|
MSLBI01
|
|
Power Source
|
Electric
|
|
Warranty
|
1 Year
|
|
After-sale Service
|
Online technical support
|
|
Material
|
metal
|
|
Shelf Life
|
1years
|
|
Quality Certification
|
ce
|
|
Instrument classification
|
Class II
|
|
Safety standard
|
GB15979-2002
|
|
Warm-up time
|
≤30min
|
|
Max CO2-concentration
|
0.4%
|
|
Noise
|
less than 55dB(A)
|
|
Power Supply
|
~ 220V, 50/60Hz
|
|
Mattress size
|
65*37cm
|
|
Trough Capacity
|
1200ml
|
|
Air filter
|
0.5μm
|
|
Infant bed tilt angle
|
+/-10 °
|
|
Air temperature control range
|
25 °C -37 °C, 37.1 °C -38 °C
|
|
Operating environment air velocity
|
<0.3 m/s
|
Detailed Images
