Microwave Steam Sterilizer MDLTA03
- Sterilize baby bottles, pacifiers, and breast pump parts quickly and effectively
- Spacious chamber with 18-liter volume and 3 trays for accommodating multiple items
- Operates at 2200W power with voltage options of 220/110V, 50/60Hz
- Offers various sterilization programs for different types of items (solid, liquid, wrapped, textile, prion)
- Provides quick sterilization cycles ranging from 15-55 minutes
- Includes drying function with a total time of 1-20 minutes
- Equipped with safety features such as B&D test, Helix test, and vacuum test
- SKU
- MDLTA03
- Brand
- MDL
- Manufactured by
- MedicalDeviceLab
- Availability
- In stock
- ✓ Worldwide shipping
Microwave Steam Sterilizer MDLTA03
Efficient microwave steam sterilization for medical and laboratory environments. The MDLTA03 delivers rapid cycle times with dual voltage support, accommodating up to 3 trays with chamber volume of 18 liters. Engineered for reliability with comprehensive test capabilities including B&D, Helix, and Vacuum testing protocols.
Clinical overview
The MDLTA03 microwave steam sterilizer is a compact, high-performance solution for medical facilities, surgical centers, and laboratory environments requiring reliable steam sterilization. With an 18-liter chamber and support for up to 3 trays, the unit accommodates diverse load configurations while maintaining rapid cycle times. The dual voltage design (220/110V, 50/60Hz) ensures global compatibility, and the 2200-watt power output delivers consistent, effective sterilization across all material types.
Engineered for clinical reliability, the MDLTA03 includes comprehensive validation testing protocols—B&D test, Helix test, and Vacuum test—ensuring sterility assurance levels (SAL) meet international standards. Multiple sterilization programs address solid instruments, liquids, wrapped items, textiles, and prion-contaminated materials, with cycle times ranging from 4 to 30 minutes depending on load type and temperature protocol.
Key features & surgeon benefits
Versatile Load Accommodation
- 18-liter chamber with 3-tray configuration
- Supports solid, liquid, wrapped, textile, and prion loads
- Compact footprint: 480×465×690 mm, 47 kg
Rapid Sterilization Cycles
- Fast cycle times: 4–30 minutes depending on program
- Total processing time 15–55 minutes including pre- and post-sterilization phases
- Drying program available (1–20 minutes)
Dual Voltage & Frequency Support
- 220/110V operation with 50/60Hz frequency
- 2200-watt power for consistent performance
- Suitable for international deployment
Comprehensive Test Protocols
- B&D test, Helix test, and Vacuum test capabilities
- Multiple temperature protocols: 121 °C and 134 °C
- Pressure control up to 210 kPa for assured sterilization
Technical specifications
| Indications | Medical and laboratory sterilization of solid instruments, liquids, wrapped items, textiles, and prion-contaminated materials |
|---|---|
| Chamber Dimension | Ø247 × 350 mm |
| Chamber Volume | 18 liters |
| Number of Trays | 3 |
| Overall Dimensions | 480 × 465 × 690 mm (W × H × D) |
| Weight | 47 kg |
| Voltage & Frequency | 220/110V, 50/60Hz |
| Power | 2200 watts |
| Sterilisation Temperatures | 121 °C and 134 °C |
| Pressure Range | 110–210 kPa |
| Cycle Times | 4–30 minutes (sterilization phase); 15–55 minutes (total cycle) |
| Packaging | As applicable |
| Warranty | 2 Year Manufacturer Warranty |
Sterilization programs & cycle parameters
| Program | Temperature (°C) | Pressure (kPa) | Sterilization Time (min) | Total Time (min) |
|---|---|---|---|---|
| Solid | 134 | 210 | 4 | 15–25 |
| Solid | 121 | 110 | 20 | 25–40 |
| Liquid | 134 | 210 | 10 | 25–50 |
| Liquid | 121 | 110 | 30 | 30–55 |
| Wrapped | 134 | 210 | 10 | 20–45 |
| Wrapped | 121 | 110 | 30 | 30–50 |
| Textile | 134 | 210 | 10 | 20–45 |
| Textile | 121 | 110 | 30 | 30–50 |
| Prion | 134 | 210 | 18 | 30–50 |
| Drying | — | — | — | 1–20 |
| B&D Test | 134 | 210 | 3.5 | 22–35 |
| Helix Test | 134 | 210 | 3.5 | 22–35 |
| Vacuum Test | — | — | — | 15–20 |
Standard instrument composition
| Item | Description | Qty |
|---|---|---|
| Single device — no multi-component set. The MDLTA03 is supplied as a complete microwave steam sterilizer unit with integrated chamber, control system, and accessories. | ||
